MPS MP6522 Brushed Motor Driver
Brushed DC motor and solenoid driver with H-bridge configuration. Integrated protection features.
Technical Specifications
| Parameter | Value |
|---|---|
| Input Voltage Range | 5.4V ~ 35V |
| Output Current | 2A |
| Package | QFN-24 (5×5) |
| Part Number | MP6522 |
| Brand | MPS / Monolithic Power Systems |
| RoHS Compliant | Yes |
Key Features
- Integrated gate driver
- Current sensing
- Stall detection
- Thermal shutdown
Product Overview
The MP6522 is a Brushed DC Motor Driver from Monolithic Power Systems (MPS), designed for high-performance motor drivers applications. Brushed DC motor and solenoid driver with H-bridge configuration. Integrated protection features. This device is suitable for robotics, industrial automation, HVAC systems, and electric vehicles. MPS MP6522 offers best-in-class integration, efficiency, and reliability, backed by MPS’s extensive application support and quality assurance.
Typical Applications
- Industrial Automation
- Robotics
- Drones
- Hvac Systems
- Consumer Appliances
Why Choose MPS MP6522?
The MP6522 from Monolithic Power Systems delivers industry-leading performance in integrated motor driver solutions for brushed, brushless, and stepper motors. Backed by MPS’s commitment to quality and innovation, this device is supported by comprehensive application notes, evaluation boards, and dedicated field application engineers worldwide.
MPS products are manufactured in ISO-certified facilities and comply with international quality standards, ensuring high reliability for demanding industrial, commercial, and consumer applications.
